Amtrol Extrol EX-30 4.4-Gallon Hydronic Boiler Expansion Tank

Product Description

Amtrol Extrol EX-30 is a 4.4-gallon in-line diaphragm expansion tank for closed-loop hydronic heating and boiler systems. It accommodates heating-system water expansion and is factory pre-charged to 12 PSIG. The 1/2-inch NPT male connection supports in-line installation. This hydronic model should not be used as a substitute for a potable-water thermal expansion tank.

Specifications

• Manufacturer / Brand: Amtrol
• Model / MPN: EX-30
• Model: EX-30 / No. 30
• Tank / maximum acceptance volume: 4.4 / 2.5 US gallons
• Diameter / height: 11 / 15 inches
• System connection: 1/2-inch NPT male
• Maximum pressure / temperature: 100 PSIG / 240 F
• Factory pre-charge: 12 PSIG
• Application: Closed-loop hydronic heating
• Limited warranty: 7 years; terms apply
• Approximate shipping weight: 9 lbs

Installation & Compatibility

Confirm the model, dimensions, connections and installation requirements against the supplied unit and manufacturer instructions. Manufacturer warranty coverage depends on the product, application and applicable written terms.
